60KW Induction Heating Machine High Safety Protection ISO Certificate

Ask Lasest Price
Brand Name :	Canroon
Certification :	CE ISO9001:2008
Price :	negotiated price
Delivery Time :	A week after confirmed payment
Payment Terms :	L/C,T/T,Western Union
Supply Ability :	2000Pieces per Week
Model Number :	CR2100

Add to Cart

Product Details
Company Profile

60KW Induction Heating Machine High Safety Protection ISO Certificate

Best price 3 phase ac motor controller asynchronous AC frequency converter variable frequency drive 50hz to 60hz motor drive

CV900G series frequency inverter included advanced technology of flux vector control.

High torque output of full frequency, quick response, perfect load adaptability,

high control precision of speed and good reliability, all of which ensure it to

meet high requirement of various field application

Voltage Class	Rated Power(KW)	Rated Output Current(A)	Adapted Motor(KW)
220V 1-phase	0.4	2.4	0.4
	0.75	4.5	0.75
	1.5	7	1.5
	2.2	10	2.2
380V 3-phase	0.75	2.5	0.75
	1.5	3.7	1.5
	2.2	5.0	2.2
	3.7	9	3.7
	5.5	13	5.5
	7.5	17	7.5
	11	25	11
	15	32	15
	18.5	37	18.5
	22	45	22
	30	60	30
	37	75	37
	45	90	45
	55	110	55
	75	150	75
	...	...	...
	500	930	500

Input	Rated Voltage, Frequency	3-phase(4T#sereis)380V;50/60HZ 1-phase(2S#series)220V;50/60HZ
Input	Allowed Voltage Range	3-phase(4T#series)320V~460V 1-phase(2S#series)160V~260V
Output	Voltage	4T#series; 0~480V 2S#series; 0~260V
	Frequency	Low frequency mode: 0~300HZ ; High frequency mode: 0~3000HZ
	Overload Capacity	G type: 110% for long-term, 150% for 1 min, 180% for 5s P type: 105% for long-term, 120% for 1 min, 150% for 1s
Control Mode		V/F control, advanced V/F control, V/F separation control, electric current vector control

	frequency	Low frequency mode: 0~300HZ ; High frequency mode: 0~3000HZ
	Overload Capacity	G type: 110% for long-term, 150% for 1 min, 180% for 5s
		P type: 105% for long-term, 120% for 1 min, 150% for 1s
Control Mode		V/F control, advanced V/F control, V/F separation control, electric current vector
Control Characters	Frequency Setting Resolution	Analog Input	0.1% of maximum output frequency
		Digital Setting	0.01 Hz
	Frequency Precision	Analog Input	Within 0.2% of maximum output frequency
		Digital Setting	Within 0.01% of set output frequency
	V/F Control	V/F Curve(voltage frequencycharacter)	Reference frequency setting 5~600 Hz, multipoint V/F curve setting, or fixed curve of constant torque, low decreasing torque 1, low decreasing torque 2, square torque
		Torque Compensation	Manual setting: 0.0~30% of rated output Automatic compensation: according to output current and motor parameter
		Automatic Current-limiting and Voltage-limiting control it within bounds based on unique algorithm, minimize	During acceleration, deceleration or steady running, detect automatically the current and voltage of motor stator, and fault-trip chance
	Senseless Vector Control	Voltage Frequency Character	Adjust pressure/frequency ratio according to motor parameter and unique algorithm
		Torque Character	Starting torque: 3.0 Hz 150% rated torque (VF control) 0.5 Hz 180% rated torque (SVC, FVC) 0.05 Hz 180% rated torque (VC) Operating speed precision in steady state: ≤±0.5% rated synchronous speed Torque response: ≤50ms VC, SVC, FVC ≤ 20ms
		Motor Parameter Self-measurement	Being able to detect parameter automatically under static state and dynamic state of motor, thus guarantee an optimum control.
		Current and Voltage Restrain	Current closed-loop control, free from current impact, perfect restrain function of overcurrent and overvoltage

Product picture:

Product Features:

4 Control Mode

V/F Control,

Advamced V/F control

V/F separation Control

Electric Current Vector Control

Ultralow Noise

Carrier freq. modulation:1-16Khz

High Running Freq.

Max. 3000Hz

Control Protection

Timely & reliable

Excellent Torque Output

V/F Control

150% rated torque in 30Hz

Electric Current Vector Control

180% rated torque in 0.5Hz

High Overload Capacity

Last for 60s with 150% rated torque

Abundant function

LCD panel, nixie tube panel of single row or double row
Pulse train I/O function
Run time and electricity consumption recording
Speed and torque control
VF separation control
Swing frequency control
Length control
PID control
Communicating function

Basic Running Wiring Diagram

Applications:

Factory workshop:

Exhibitions:

Packaging:

Certifications:

Shipping
